Hikvision DS-2DF8225IH-AEL DarkFighterX 2MP With 25X Optical Zoom

Web ID: 856

Hikvision is leading the industry with innovative video surveillance products and solutions, with the introduction of the DarkFighter X series. Using cutting-edge technology, it delivers the next level of performance for night surveillance. The technology can provide colourful, sharp images right down to the lowest light levels of 0.001 lux. The DarkFighter X Series takes inspiration from the way the human eye works. Eyes use different cells to collect colour and brightness information, which the brain then merges. The DarkFighterX cameras take information from an IR sensor (for brightness) and information from a visible light sensor (for colour) and combines them to provide the best of both worlds, one bright full-colour image. The DarkFighterX series includes a PTZ and bullet camera both come with optical defog, 25x optical zoom, 2MP resolution and smart detection. They also boast the H.265+ codec and are weatherproof to IP66 standard.
Manufacturer PN: DS-2DF8225IH-AEL
Warranty: 3 Year
Manufacturer Website

$3782

DS-2DF8225IH-AEL
DarkFighterX 2MP With 25X Optical Zoom

Key Features

  • Dual sensors - 2 x 1/2.8" CMOS
  • 2 megapixel - 1080P @25fps/30fps
  • Color: 0.001lux/F1.5, B/W: 0.0001ux/F1.5
  • H.265+/H.265/H.264+/H.264/MJPEG
  • Wiper
  • 200m infrared
  • 120dB wide dynamic range
  • Pan range: 360 degrees endless
  • Tilt range: -20 degrees~90 degrees(Auto Flip)
  • Pan speed: 0.1 degrees ~160 degrees/s
  • Tilt speed: 0.1 degrees ~ 120 degrees/s
  • Optical zoom:25x, focus: 4.8-20mmv
  • Supports SD/SDXC card up to 128GB
  • Call Us For Bracket Options
Camera
Image Sensor:   2× 1/2.8" progressive scan CMOS
Effective Pixels:   1920(H)x1080(V)
Signal System:   PAL/NTSC
Minimum Illumination:   Color: 0.0004 Lux @(F1.5, AGC ON)
B/W: 0.0001 Lux @(F1.5, AGC ON)
0 Lux with IR
AGC:   Auto/Manual
BLC:   ON/OFF
HLC:   Support
Smart defog:   Support
WDR:   120dB
Shutter Time:   50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s
Day& Night:   ICR
Digital Zoom:   16X
Privacy Mask:   24 programmable privacy masks
Auto Focus:   Auto / Semi-automatic / Manual
Rapid Focus:   Yes
Lens
Focal Length:   4.8 mm to 120 mm, 25× Optical
Zoom Speed:   Approx. 4.4 s (optical lens, wide-tele)
Field of View:   Horizontal field of view: 58.2° to 3.2° (wide-tele)
Vertical field of view: 32.7° to 1.8° (wide-tele)
Diagonal field of view: 66.8° to 3.7° (wide-tele)
Minimum Working Distance:   10-1500mm(Wide-Tele)
Aperture Range:   F1.5~F3.5
Pan & Tilt
Pan Range:   360°endless
Pan Speed:   Configurable, from 0.1°/s to 210°/s, Preset Speed: 280°/s
Tilt Range:   -20°~90°(Auto Flip)
Tilt Speed:   Configurable, from 0.1°/s to 150°/s, Preset Speed: 250°/s
Proportional Zoom:   Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset:   300
Patrol:   8 patrols, up to 32 presets per patrol
Pattern:   4 patterns, with the recording time not less than 10 minutes per pattern
Power-off Memory:   Support
Park Action:   Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display:   ON/OFF
Smart-tracking:   Manual Tracking, Auto Tracking (support tracking specified target types such as human and vehicle), Event Tracking
Wiper:   Optional
Infrared
IR Distance:   200m
IR irradiation angle:   Adjustable by zoom
Alarm
Alarm Input:   7 Inputs
Alarm Output:   2
Alarm Linkage:   Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel
Network
Ethernet:   10Base -T, /100Base-TX, RJ45 Connector
Main Stream:   50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720)
60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720)
Sub Stream:   50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240)
Third Stream:   50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480, 320 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480, 320 × 240)
Video Compression:   Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
ROI encoding:   Eight fixed region for each stream
Audio Compression:   G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Mode:   OFF/Audio input/Audio output
Simultaneous Live View:   Up to 20 channels
Three-Stream:   Support
Storage:   Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
Security Measures:   User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering
Client GUI
Camera Control:   Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode
Date & Time Display:   Time: Week: Date, 6 formats on the Client
Client:   Support iVMS-4200
Web Browser:   IE 7+, Chrome 18 - 42, Firefox 5.0 +, Safari 5.02 +
General
RS-485 Protocols:   HIKVISION, Pelco-P, Pelco-D, self-adaptive
Power Supply:   24 VAC & Hi-PoE
Power Consumption:   Without wiper: 24 VAC, max. 68 W (max. 12 W for heater, and max. 15 W for IR), Hi-PoE, max. 60 W
With wiper: 24 VAC max. 70 W (max. 12 W for heater, and max. 15 W for IR), Hi-PoE, max. 60 W
Working Temperature/Humidity:   Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: ≤ 90%
Protection Level:   IP67 Standard. Lightning protection, surge protection and voltage transient protection meets IEC61000-4-2-2/3/4/5/6
Dimensions:   Φ 266.6 mm × 437 mm (Φ 10.50" × 17.20")
Weight (approx.):   8kg (approx.17.64lb)
