Integriti Prisma Terminal, White
Web ID: 415
The Prisma Terminal is a stylish and cost-effective new user
interface for the Concept 4000 System. Featuring a full colour LCD
screen, the Prisma Terminal leverages its user experience from
commonplace mobile communications and personal entertainment
devices. It offers a simple to use icon, function key and scroll wheel
based navigation system, together with large easy to read text.
As a result the new Prisma Terminal provides a delightful user
experience. Equipped with variable colour keypad backlight and
auto-dimming backlight technology, the Prisma Terminal can be
tailored to blend in or stand out in any environment.
Manufacturer PN: IR-996000
Warranty: 2 Year
Manufacturer Website
Physical
Housing Dimensions: Height 162mm : Width 88mm : Depth 15mm
Installation Environment: 0° - 40°C @ 15% to 85% relative humidity
(noncondensing)
Electrical
Input Voltage: 11V – 14V DC
Operational Current: Auto current limiting
Typically less than 100mA @12V
Outputs
Speaker: 8-bit digital sound
LED Indicators: Array of 8, Auto-dimmable bicolour LED
User Interface
LCD Screen: 320 x 240 (QVGA) colour LCD
LCD Backlight: White backlit, Auto-dimmable
Keypad Backlight: Variable-colour RGB, Auto-dimmable
